How to replace the LED High Bay Light Fixtures?

2015-03-18 21:07:10

The 120 Watt LED Low Bay Fixture is designed to replace traditional high intensity discharge (HID) lamp fixtures in industrial and other large area lighting applications. High Pressure Sodium and Metal Halide are very common in warehouses and industrial buildings,These superior quality LED High Bay Fixtures offer maximum energy savings, reduce maintenance costs, and operate at any voltage from 100~277 VAC. Limited quantity available. Price for each. Reflector Sold Separately.

MODEL NO:   High Bay Light 120W
Input voltage: AC85 – 265V
Frequency Range: 47 – 62Hz
Power Factor: >0.95
Power Efficiency: > 0.85
LED Power Consumption:  135W
LED Luminous Efficiency:  ≥85lm/w (Tj=25°)
LED Luminous Flux:   8.000lm (Tj=25°)
Illumination (E/LX):
              Height=6m    ≥45LUX
              Height=8m    ≥28LUX
  Height=10m   ≥18LUX
  Height=12m   ≥12LUX
Range:
  Height=6m                12mx12m
  Height=8m                15mx15m
  Height=10m               18mx18m
  Height=12m               21mx21m

Correlated Color Temperature(CCT):  Cool White:5000 – 7000K
Color Rendering Index(CRI):             >70
Max lighting intensity angle:   Horizontal Axis: 0°    Vertical axis: 0°
Beam angle:   90°
LED Q’ty:     120pcs
Junction temperature(Tj): 65℃±10%(Ta=25℃)
Working Temperature: -25 ~ 50℃
Working Humidity:   10% - 85%
Storage temperature: -40 ~ 85℃
Working Life: 30,000Hrs
Warranty Period: 3-year
IP Rating: IP65
Housing Material:  Aluminum Alloy – glass
